How to Recover Files from Mac APFS using Windows PC?

Windows may detect a Mac APFS disk yet refuse to open it. These five routes cover intact files, deleted data, damaged containers, encryption, plus failing hardware.

Quick answer

Do not accept Windows' offer to format the APFS drive. If the device appears in Disk Management, scan the whole physical disk with Disk Drill, preview the missing files, then recover them to a different drive. Create a byte-to-byte image first if the source is unstable.

!

Stop writing to the APFS drive. Formatting, CHKDSK, partition repair, new file copies, or repeated scans can overwrite recoverable data. Power off a clicking or frequently disconnecting drive.

★ Editorial pick ★ 4.5 / 5

Scan an APFS Drive on Windows → Disk Drill

Scans APFS, RAW, or unmountable storage · Previews found files before recovery · Runs on Windows 10–11

✓ APFS scan support ✓ Byte-to-byte backups ✓ Windows plus macOS versions
Try the scan →

When DIY APFS Recovery Is Too Risky

Do not keep testing software on a hard drive that clicks, stalls the PC, or disappears during reads. Those symptoms point toward hardware trouble, where every extra spin-up may consume part of the drive's remaining usable life.

DIY work is also a poor gamble when the only copy holds legal records, paid client work, or years of family photos. In that case, leave the disk powered off while you compare professional evaluations.

Choose the Right APFS Recovery Method for a Windows PC

Match the method to the drive's condition, not just the error shown by Windows.

Method Best for Time Success rate
1. Scan the APFS Drive With Disk Drill TRY FIRST Deleted files or an unreadable healthy drive ~15–60 min ● 82%
2. Image the APFS Drive Before Scanning Slow or mildly unstable storage ~1–12 hr ● 76%
3. Mount the APFS Volume With Paragon Existing files hidden from Windows ~10–30 min ● 90%
4. Move the Recovery Job to a Mac FileVault or complex Apple storage ~30 min–several hr ● 72%
5. Send the APFS Drive to a Recovery Lab Physical failure or priceless data ~3–14 days ● 68%

Top 5 Ways to Recover Files From Mac APFS Using a Windows PC

01

Scan the APFS Drive With Disk Drill

Best first move for a healthy external Mac drive that Windows can detect

~15–60 min
Difficulty Easy
You need Disk Drill plus a second drive
Works for Windows 10–11

Windows File Explorer may not open APFS, but recovery software can still inspect the physical device. Disk Drill for Windows supports APFS scans, including drives that appear unreadable or unmountable.

  1. Stop using the affected Mac drive. Do not format it when Windows displays a format prompt.
  2. Connect the APFS drive directly to the PC. Use a powered enclosure if a desktop hard drive needs more power than USB supplies.
  3. Install Disk Drill on the Windows system drive or another healthy disk, never on the APFS source.
  4. Open Disk Drill, select the whole physical drive, then click Search for lost data. Choosing the device instead of one visible partition gives the scan more room to find a damaged APFS container.
  5. Review the results by file type, date, name, or folder. Preview several important files before paying for or starting a large recovery.
  6. Select the files, click Recover, then save them to a different physical drive formatted as NTFS or exFAT.
Disk Drill Review ↗
i A working preview is a useful sign, though no preview can guarantee that every recovered file will be complete.
Visit the Disk Drill website
02

Image the APFS Drive Before Scanning

Safer for a drive that freezes, slows down, disconnects, or reports read errors

~1–12 hr
Difficulty Moderate
You need Disk Drill plus spare storage
Works for Unstable HDDs, SSDs, USB drives

A sector-level image reduces repeated access to questionable hardware. Disk Drill can create a plain byte-to-byte copy on Windows, after which you scan the image rather than stressing the original disk.

  1. Prepare a healthy destination disk with free space at least equal to the full capacity of the APFS source. A 2 TB source needs roughly 2 TB of available space.
  2. Connect both disks to the Windows PC, then close any program that tries to index, repair, or initialize the APFS device.
  3. Open Disk Drill, choose Byte-to-byte Backup, select the physical APFS drive, then click Create backup.
  4. Save the image as a .dd file on the healthy destination disk. If the source becomes unusually hot or repeatedly drops offline, stop the process.
  5. Disconnect the original drive once the image finishes. Attach the image inside Disk Drill, scan it for lost data, then preview the results.
  6. Recover selected files from the image to a separate folder or physical disk.
i If the drive clicks, scrapes, fails to spin, or vanishes every few seconds, skip imaging at home because repeated power cycles can worsen mechanical damage.
Read the Disk Drill byte-to-byte backup guide
03

Mount the APFS Volume With Paragon

Useful when files still exist but Windows simply cannot open the Mac-formatted drive

~10–30 min
Difficulty Easy
You need APFS for Windows plus spare storage
Works for Readable basic APFS volumes

This is file access rather than deleted-file recovery. Paragon APFS for Windows can mount supported APFS volumes in File Explorer, letting you copy visible folders to a Windows disk without reformatting the source.

  1. Confirm that the files are merely inaccessible from Windows, not deleted. Do not use this method to write new data onto a volume with missing files.
  2. Install APFS for Windows by Paragon Software, then restart the PC if requested.
  3. Connect the APFS disk. Wait for Paragon to assign a drive letter, then open This PC.
  4. Copy the most valuable folders first to an NTFS or exFAT destination. Start with small documents or photos so you can verify that the volume remains stable.
  5. Open a sample of copied files from the destination disk. Check large videos, archives, databases, plus other formats that can hide partial corruption.
  6. If the volume does not mount, appears incomplete, or asks for unsupported encryption details, stop. Return to a read-only recovery scan or use a Mac.
i Avoid editing, renaming, or deleting anything on the APFS source. Treat the mounted volume as read-only even if the driver offers write access.
Check Paragon APFS volume support
04

Move the Recovery Job to a Mac

Better for FileVault, Apple hardware storage, Fusion Drive, or complex APFS layouts

~30 min–several hr
Difficulty Moderate
You need A compatible Mac plus destination disk
Works for Encrypted or complex APFS storage

A Windows PC is not always the right host. A borrowed or secondary Mac may recognize APFS structures, FileVault prompts, snapshots, or Apple-specific storage layouts that Windows tools cannot handle cleanly.

  1. Shut down the original Mac if it still works. Avoid normal startup when the missing files came from its internal SSD because background activity may reduce recovery chances.
  2. For an external APFS disk, connect it to another Mac. For removable internal storage, use the correct enclosure or adapter without modifying the drive.
  3. If FileVault protects the volume, have the account password or recovery key ready. Encryption cannot be bypassed by ordinary recovery software.
  4. Install Disk Drill for macOS on a healthy disk. Grant the permissions requested by macOS, then select the affected device or its byte-to-byte image.
  5. Run the scan, preview important items, then recover them to a different external disk. Never restore files to the source APFS container.
  6. If the files belong to a modern Mac's soldered internal SSD, use that Mac's supported recovery or sharing route rather than attempting physical removal.
i A Mac does not defeat TRIM or missing encryption credentials. It mainly provides better access to Apple-specific storage configurations.
Read about encrypted APFS recovery
05

Send the APFS Drive to a Recovery Lab

Last resort for physical failure, irreplaceable files, or soldered Mac storage

~3–14 days
Difficulty Easy to arrange
You need A reputable recovery service
Works for Physical or severe logical failure

Software cannot repair failed heads, damaged electronics, seized motors, or NAND-level faults. A lab is also the sensible first choice when one more DIY attempt would put unique business records, research, or family photos at risk.

  1. Power the device off if it clicks, grinds, smells burnt, was dropped, or disconnects too often to image reliably.
  2. Write down what happened, the Mac model, whether FileVault was enabled, plus which files matter most. Keep passwords separate from the shipped package.
  3. Choose a lab that provides an evaluation, a written quote, a recoverable-file list, plus a clear policy for unsuccessful cases.
  4. For a loose hard drive, place it in an antistatic bag with firm padding. Do not open the casing, freeze the drive, swap circuit boards, or run repair utilities.
  5. For internal storage in a recent Mac, send the complete Mac unless the lab specifically requests something else. Apple security hardware may tie storage access to the original logic board.
  6. Inspect the returned files on at least two devices, then make two backups before erasing or replacing the original storage.
i Ask whether the lab has direct APFS plus FileVault experience. General computer repair shops often outsource this work.

Which APFS Recovery Method Should You Use?

Start with Disk Drill on Windows when the APFS device is physically healthy, visible in Disk Management, yet inaccessible through File Explorer. Make a byte-to-byte image first if reads are slow or unreliable.

Use Paragon only to copy files that still exist. Move to a Mac for FileVault or unusual Apple storage, while clicking noises, repeated disconnects, or irreplaceable data call for a recovery lab.

Recover the smallest high-priority folder first, verify its files, then continue with the rest without writing anything back to the APFS source.

Common Questions About APFS Recovery From Windows

Can I recover APFS files on a Windows PC without a Mac?
Yes, but Windows cannot read APFS on its own. You need a tool that understands APFS or a service that can access the Mac drive from Windows.
What is the easiest way to open an APFS drive in Windows?
The simplest path is to use a third-party APFS reader or recovery app on Windows, then copy the files you need to a separate drive. If the disk is damaged, use recovery mode instead of trying to browse it like a normal drive.
How do I recover deleted files from an APFS drive using Windows?
Connect the Mac drive to the Windows PC with a compatible adapter or enclosure, then scan it with APFS recovery software. Save recovered files to a different disk so you do not overwrite anything.
Why does my Windows PC say the APFS drive is unformatted?
That happens because Windows does not natively support APFS. Do not initialize or format the disk, since that can make recovery harder.
Can I use Disk Management on Windows to fix an APFS drive?
No, Disk Management is not the right tool for APFS recovery. It may show the drive, but it cannot repair or mount APFS volumes safely.
What software should I use on Windows for APFS recovery?
Use a recovery tool that specifically lists APFS support and can scan external Mac drives. Look for read-only scanning, file previews, plus recovery to a different destination.
How do I recover photos from a Mac APFS drive on Windows?
Scan the APFS volume in the recovery app, then filter by image types such as JPG, HEIC, PNG, or RAW. Preview before restoring so you avoid pulling back junk files.
Can I recover files from a crashed Mac that used APFS?
Often yes, if the drive itself is still readable through Windows hardware. If the Mac will not boot, remove the internal drive, connect it through an enclosure, then scan it from Windows.
What if the APFS drive is encrypted with FileVault?
You will usually need the password or recovery key before any file can be opened. Without that, Windows software may detect the volume but still fail to decrypt the contents.
Is it safe to install recovery software on the same Windows PC that is scanning the Mac drive?
Yes, as long as the Mac drive is only being read, not written to. Install the software on the Windows system drive, then save recovered files somewhere else.
How long does APFS recovery take on Windows?
It depends on drive size, drive health, plus whether the scan is quick or deep. A healthy external disk is faster, while a failing disk can take much longer.
What should I do before trying APFS recovery from Windows?
Stop using the Mac drive right away, then connect it in read-only mode if possible. Avoid running repair tools before recovery unless you already have a backup.
Can Windows recover APFS snapshots or Time Machine backups?
Sometimes, if the recovery tool can read APFS snapshots. Time Machine backups can be trickier, so look for software that can browse snapshots or backup structures directly.
What file types can I usually recover from APFS on Windows?
Most recovery tools can restore common documents, photos, videos, audio, plus archives. The exact list depends on the software, not the file system itself.
Should I reformat the APFS drive to use it on Windows?
Not if you still need the data. Reformatting erases the current volume structure, so recover files first, then decide whether you want a Windows-friendly format later.
What is the difference between APFS recovery software, cloning, plus file extraction?
Recovery software scans the drive for lost data, cloning makes a sector-by-sector copy, plus file extraction just copies what is still visible. If the disk is failing, cloning first is usually the safer move.
When should I send an APFS drive to a professional instead of using Windows recovery?
Choose a pro if the drive is clicking, not spinning, has major physical damage, or fails to appear consistently. DIY recovery is better for logical issues, accidental deletion, or minor corruption.
